How To Install LED DRL Boards On Your 2020+ Toyota Supra GR

Welcome to our guide, where we introduce an innovative lighting upgrade for your 2020+ Toyota Supra GR. Our Single Color and RGB+W DRL Boards are designed to elevate your vehicle's aesthetics and functionality. This step-by-step guide will help you navigate the installation process effortlessly.

Unleash Vibrant Colors And Customization

Our Single Color DRL Boards are available in three stunning shades: Lemon-Yellow, Red, and Blue. Choose the color that best complements your Supra GR's exterior and express your personality on the road. Whether you desire a bold and vibrant look or a subtle and sleek aesthetic, our Single Color DRL Boards have you covered.

For those seeking an even more immersive lighting experience, our RGB+W DRL Boards are the ultimate choice. With the help of our dedicated smartphone app, you can unlock a world of possibilities. Customize your Supra GR's lighting with dynamic color patterns, themes, and animations. From pulsating hues to smooth color transitions, the RGB+W DRL Boards allow you to curate a lighting display that matches your unique style and preferences.

Installation Process

Step 1: Removing The Fender Liners
  1. To begin the installation process, it is essential to remove the fender liners. This can be achieved by carefully removing the 11 10-millimeter bolts and one speed clip.
Step 1 Image
Step 2: Removing The Bumper And Headlights
  1. Next, you need to remove the bumper and headlights to access the DRL components. Start by removing the 12 7-millimeter bolts across the bottom of the bumper. Pop the hood and remove the six speed clips from the fender liner covers. Remove the hood gasket, and then proceed to remove the 10 10-millimeter bolts across the top of the bumper.
Step 2 Image
Step 3: Dismantling The Headlight Assembly
  1. With the headlight assembly removed, it is time to dismantle the components necessary for installing the DRL boards. Remove the three T20 screws holding in the heat sink and pull the heat sink away from the headlight. Next, unplug the factory DRL and remove the two T10 screws.
Step 3 Image
Step 4: Installing the New LED DRL Boards
  1. Take the new LED daytime running light boards and replace them with the original ones. Make sure they are secure and tight. Once the LED daytime running light boards are in position, reconnect the connectors to the new boards. Double check that all connections are secure to ensure proper functionality.
Step 4 Image
Step 5: Installing The Bluetooth controller
  1. This step is only for the RGB+w varinat! To properly control the light of the DRL boards, it is necessary to install the Bluetooth controller. Place the controller in the engine compartment, using either double-sided adhesive or zip ties to secure it to the underside of the core support.
Step 4 Image
Step 6: Reassembling The Headlight Assembly
  1. With the DRL boards and LED driver installed, reassemble the headlight assembly by reconnecting the main headlight connector and putting the headlight back into place.
Step 5 Image
Step 7: Reinstalling The Bumper
  1. In the final step, reattach the bumper to the car. Place the bumper back on the car, ensuring a proper fit, and plug back in the sensor harnesses.
Step 6 Image

Conclusion

Congratulations! You have successfully installed DRL boards on your 2020+ Toyota Supra GR. Remember to refer to the manufacturer's instructions and take your time during the installation process to ensure a seamless and professional outcome.

Disclaimer: This installation guide is provided for informational purposes only. Always exercise caution and consult your vehicle's manual or seek professional assistance if you are unsure about any step of the process.
